Rocktech industrial PCs have administrator privileges enabled by default, so you can proceed directly;
| Common Project Requirements / Pain Points | Terminal equipment needs the screen, host, touch and communication interfaces integrated as one | The site needs to connect serial devices, USB peripherals and control modules at the same time | Device deployment environments have inconsistent network conditions | The project needs to balance cost, performance and future expansion | Terminal equipment needs long-term operation and on-site maintenance |
|---|---|---|---|---|---|
| How the MDC-10720P solves it | Integrates a 10.1-inch capacitive touchscreen, RK3568 SoC, Android 11 / Linux, networking and multiple interfaces | Provides RS232×2, RS485×2, USB 2.0×3, USB 3.0×1, Type-C OTG and GPIO IO×4 | Supports Gigabit RJ45 and Wi-Fi & BT, with optional 4G module and external 4G antenna | Available in 2+16 GB and 4+32 GB configurations, with storage selectable to suit project needs | Supports DC 12V power input, a -10℃~60℃ operating temperature, a TF card slot and a Recovery button opening |
| Customer Value | Fewer adaptation steps for a cleaner product structure and faster project progress | More flexible peripheral connection and easier commissioning, with fewer extra adapters | Suits wired, wireless and mobile networks for more flexible deployment | Easy selection by project tier, covering both prototype testing and volume delivery | Easier installation, commissioning, maintenance and on-site application deployment |
| Part NO. | MDC-10720P-L10 | MDC-10720P-L11 |
|---|---|---|
| Configuration | LPDDR4X 2GB EMMC 16GB |
LPDDR4X 4GB EMMC 32GB |
| Screen Brightness | 300 cd/m² | 300 cd/m² |
| Interfaces | RS232×2, RS485×2 USB 2.0×3, USB3.0×1, USB OTG×1 |
RS232×2, RS485×2 USB 2.0×3, USB3.0×1, USB OTG×1 |
| Part Number | MDC-10720P |
|---|---|
| CPU | RK3568 quad-core Cortex-A55, up to 2.0 GHz |
| Configuration | DDR: onboard 2 GB, expandable to 4 GB eMMC: onboard 16 GB, expandable to 32 GB/64 GB |
| Android OS | Android 11 / Linux |
| Dimensions | 262.3×176.3×31.5mm |
| Brightness | 300 cd/m² (Typ) |
| Resolution | 800×1280 |
| Viewing Angle | Full Viewing Angle |
| UART | RS232×2, RS485×2 |
| USB | USB 2.0×3, USB3.0×1, USB OTG×1 (Type-C) |
| Audio | 1x mono MIC / stereo HP, 1x stereo SPK |
| GPIO | IO×4 |
| LAN | 1x RJ45 10M/100/1000Mbps adaptive Ethernet port |
| Wi-Fi | Wi-Fi & BT module |
| SIM Card | Standard SIM card |
| Power | DC 12V input, DC 5.5×2.1 mm |
| TF Card | 1x TF card slot |
| Button Openings | 1x Recovery button opening |
| Environment | Temperature: -10℃~60℃ Humidity: 0%~90% RH, non-condensing |
| Interface Direction | Serial Communication | USB / OTG | Network Communication | Audio & Control Expansion |
|---|---|---|---|---|
| Specification Source | RS232×2, RS485×2 | USB 2.0×3, USB 3.0×1, USB OTG×1 (Type-C) | Gigabit RJ45, Wi-Fi & BT, standard SIM card, optional 4G | MIC / HP, SPK, GPIO IO ×4, TF card, Recovery button opening |
| Customer Value | Suitable for serial control, data acquisition and device communication peripherals, meeting multi-device connection needs. | Ideal for scanners, printers, readers, debugging and other peripherals, extending terminal capability. | Supports wired, wireless and mobile networking to suit different on-site network conditions. | For expanding audio interaction, simple control, storage and on-site maintenance. |
| Part NO. | MDC-10720P-L10 | MDC-10720P-L11 |
|---|---|---|
| Configuration | LPDDR4X 2GB EMMC 16GB |
LPDDR4X 4GB EMMC 32GB |
| Screen Brightness | 300 cd/m² | 300 cd/m² |
| Interfaces | RS232×2, RS485×2 USB 2.0×3, USB3.0×1, USB OTG×1 |
RS232×2, RS485×2 USB 2.0×3, USB3.0×1, USB OTG×1 |
| Type | 4G Module | 4G Module | 4G Module | Adapter | External Wi-Fi Antenna | External 4G Antenna |
|---|---|---|---|---|---|---|
| Part NO. | EC200A-CN | EC200N-CN | EG800AK-CN | Chinese Standard | 2.4G Suction Antenna | 4G Suction Antenna |
| Description | Cat4, Mini PCIe | Cat1, Mini PCIe | cat1 LCC | 12V3A | 3M Extension Cable | 3M Extension Cable |
| Pairing Direction | 4G Module / External 4G Antenna | External Wi-Fi Antenna | Adapter | Barcode scanners / card readers / printers and other peripherals | Sensors / control boards / industrial equipment |
|---|---|---|---|---|---|
| Suitable Projects | Smart lockers, mobile networked terminals, equipment where on-site cabling is difficult | Commercial terminals, in-store equipment, wireless network deployment scenarios | Sample testing, complete terminal delivery, volume deployment | Self-service, smart catering, vending equipment, identity interaction terminals | Smart lockers, industrial control, equipment acquisition and status monitoring |
| Customer Value | Improves networking flexibility and adapts to different on-site network conditions | Enhances the configurability of wireless access schemes | More complete testing and delivery accessories | Expands interaction and closed-loop business capability through USB / serial ports | Supports device connection and control via RS232 / RS485 / GPIO |
